| Chassis | "Chassis, length adjustment drawbar, cross members, manufactured from S700 steel grade via Robotic welding machine"
|
| Towing Eye | Ø50mm towing eye for use with 50mm bolt couplings.
|
| Turntable | Ø 1200 mm bolt-mounted double row ball bearings.swivelling 5.th Wheel |
| Painting | "Steel blasted accordingly to SAE 2,5 norm+ Zinc phosphate surface-coated + KTL dip coated+ acrylic based final coat in colour RAL 7043 + oven dried. New type of paint with zinc phosphate (similar to Nova l). 10 YEARS WARRANTY AGAINST RUST THROUGH ."
|
| Axles | 2 pieces SAF CD Brand axles with a capacity of 9 tonnes, axles with air suspension and 120 offset disc brakes.
|
| Landing Gear | Telescopic landing gear with 12 tonnes capacity and one speed landing gears painted in black
|
| Brake System | "Standart EBS brake system with 2 modules and 2 sensors (2S/2M) -RSS (Road Stability Support) system compliant to ECE R13 -Pneumatic brakes with double circuit. -Suspension system with lowering & lifting valves -"
|
| Lighting System | "-Lighting system with 24 Volt according to EC 76/756 -LED lighting set. -LED side, front and back marker lamps with reflectors. -Bulkhead division box with 2x7 pol DIN ISO 1185 and DIN ISO 3731 or 1x15 pol DIN ISO 12098."
|
| Tyres and Rims | "-4 pieces Steel Rims with 120 offset -4 pieces of tyres 385/55 R 22.5 conformant to 458/2011 EU. Rims painted in silver RAL 9006. Choice of ORTHAUS TRAILERS."
|
| Included Accessories of Chassis | "-Rear bumper, made of steel, conformant to ECE R 58. -4 pieces of mudguards conformant to EC 109/2011 EU + 2 pieces of anti-spray mud guards on 2nd axle. -2 pieces yellow wheel chokes with holder."
|
| Admission Plates | Vehicle satisfies to the EC type-test with Certificate of Conformity (CoC). Two reflector plates vertically placed on the rear wall (565x200 ECE-R70). ECE 104 reflector tapes red on the back, yellow on sides. |
