| Chassis | High-strength chassis manufactured from S700MC (stronger than ST52-3 steel) via submerged welding machine
|
| Painting | Sandblasting according to SAE 2.5 standard, epoxy-based primer with high corrosion resistance after zinc-based primer, finishing with RAL 7021 acrylic resin-based paint, oven-dried
|
| Coupling | Ø 2” (50.8 mm) coupling point conformant to SAE and DIN 74/08 Standards
|
| Axles | 3 x 9 ton capacity 120 mm offset disc brake air suspension axle sets; Automatic and manual lifting system on the first axle; The axle can be lifted by braking 3 times and pressing the button
|
| Landing Gears | Telescopic landing gears with 24 tonnes capacity and two-speed landing gears painted in black
|
| Brake System & Lifting Axle | EBS-E Plus brake system with 2 modules and 2 sensors (2S/2M) according to Regulation ECE R13.11; RSS (Road Stability Support) system; Pneumatic brakes with double circuit; Suspension system with manual lowering & lifting valves
|
| Lighting System | 24 Volt lighting system according to Regulation ECE R48.06; LED side marker lamps with reflectors; Reflective band located on sides and at the rear; Bulkhead division box with 2x7 pole DIN ISO 1185 and DIN ISO 3731 or 1x15 pole DIN ISO 12098
|
| Tyres and Rims | 6 pieces Steel Rims with 120 offset; 6 pieces of tyres 385/55 R 22.5 conformant to 2015/166/EU; Rims painted in silver RAL 9006
|
| Container Positions | 1x20 Ft rear; 1x20 Ft central; 2x20 Ft; 1x30 Ft HC & ISO; 1x40 Ft High cube; 1x45 Ft HC (carriable at 42.5 ft position)
|
| Included Accessories of Chassis | Side protection barriers made from galvanized sheet metal according to Regulation ECE R73.01; Extendable rear bumper for 45 ft Container transport conforming to ECE R58.03; Removable front support guides; Lifting brackets for tunnel-free container transport; Extendable full telescopic rear chassis for various container positions; Effortless transition from loading to driving position for 20 ft and 30 ft containers; User-friendly control panel; Pneumatic locking system; Twist lock box for container locks; Easy extension system with two wheelbase positions; 6 pieces of mudguards conformant to 2015/166/EU + 6 pieces of anti-spray mud guards; 2 pieces yellow wheel chocks with holder; Plastic document box; 2 pcs ferry rings; 1 piece fire-extinguisher box |
