| Chassis | Chassis manufactured from S700MC via Robotic welding machine; Upper structure cross members & side profiles from 5500 grade steel; Cross members positioned 400-450 mm center to center
|
| Painting | Steel blasted accordingly to SAE 2.5 norm + Zinc phosphate surface-coated + KTL dip coated + acrylic based final coat in colour RAL 7021 + oven dried; 10 YEARS WARRANTY AGAINST RUST THROUGH
|
| Coupling | Ø 2” (50.8 mm) coupling point conformant to SAE and DIN 74/08 Standards
|
| Axles | 3 pieces axles with a capacity of 9 tonnes, axles with air suspension and 120 offset disc brakes
|
| Landing Gears | Telescopic landing gears with 24 tonnes capacity and two-speed landing gears painted in black
|
| Brake System & Lifting Axle | EBS brake system with 2 modules and 2 sensors (2S/2M); RSS (Road Stability Support) system compliant to ECE R13; Pneumatic brakes with double circuit; Suspension system with lowering & lifting valves
|
| Front Panel | Steel front panel with steel corner pillars and internal protection plate with 350 mm height
|
| Curtain System | 3 sliding pillars on each side, 900 gr/m² sliding curtain, no sideboards or aluminium side planks
|
| Roof | Sliding roof opening from rear, with 175 mm roof rails
|
| Doors | Barn type aluminium doors with two wings; each wing opens at a 270° angle, equipped with two locking mechanisms and mounted with four hinges
|
| Floor | 30 mm plywood planks with slip-resistant resin coating; suitable for forklift loads up to 5460 kg (EN 283 standard)
|
| Lashings | 13x2 lashing rings with a capacity of 2 tonnes, mounted on the floor
|
| Lighting System | 24 Volt lighting system according to EC 76/756; LED lighting set with LED side, front, and back marker lamps with reflectors; Bulkhead division with 2x7 pol DIN ISO 1185 and DIN ISO 3731 or 1x15 pol DIN ISO 12098
|
| Tyres and Rims | 6 pieces Steel Rims with 120 offset; 6 tyres 445/45 R 19.5 conformant to 458/2011 EU; Rims painted in silver RAL 9006 (ORTHAUS TRAILERS brand choice)
|
| Included Accessories of Chassis | Side protection barriers made from anodised extruded aluminium profiles conformant to ECE R73; Steel rear bumper conformant to ECE R58; 6 mudguards conformant to EC 109/2011 EU + 2 anti-spray mud guards on 3rd axle; 2 yellow wheel chocks with holder; Fire extinguisher holder for 6-9 kg extinguishers; 8 Ro-Ro rings; Pull-out ladder mounted under side rave at the rear of chassis |
