| Chassis | Chassis manufactured from S700MC steel grade with robotic welding machine
|
| Painting | Steel blasted accordingly to SAE 2.5 norm + Zinc phosphate surface-coated, dip coated + acrylic based final coat in colour RAL 7021 + oven dried
|
| Coupling | Ø 2” (50.8 mm) coupling point according to SAE and DIN Standards
|
| Axles | 3 axles with a capacity of 9 tonnes and air suspension with 120 offset disc brake system; Manual lifting system on the first axle (optional automatic lifting system)
|
| Landing Gears | Telescopic landing gears with 24 tonnes capacity and two-speed landing gears painted in black
|
| Brake System & Suspension | EBS brake system with 2 modules and 2 sensors (2S/2M) according to Regulation UNECE R13.11; RSS (Road Stability Support) system; Pneumatic brakes with double circuit; Suspension system with manual lowering & lifting valves
|
| Lighting System | Lighting system with 24 Volt according to Regulation ECE R48.06; Reflectors on sides and rear; LED side and front marker lamps; Rear marker lamps near the bumper; Bulkhead division box with 3 sockets |
| Tyres and Rims | 6 pieces steel RAL 9006 painted rims with 120 offset; 6 pieces of tyres 385/65 R 22.5 conformant to 2015/166/EU
|
| Standard Accessories of Chassis | Side protection barriers made from anodised extruded aluminium profiles (ECE R73.01); Steel rear bumper with ORTHAUS-specific design (ECE R58.03); Rear ramp rubber chocks; 2 yellow wheel chocks with holder; Basket-type double spare wheel holder; 4 half mudguards + 2 anti-spray mudguards; 2 pairs of ferry rings; 1 fire extinguisher with casing; 1 plastic tool box; 1 plastic document box; 1 water tank (CE certified); Foldable ladder at the rear door made of galvanised steel
|
| Bodywork | Floor supported by high-strength sheets and 30 mm thick plywood resistant to 7200 kg forklift load; Standard height of steel front wall 2700 mm, fully mounted with bolts & nuts
|
| Included Accessories of Body | Sliding roof and side awning (RAL9006) with fast and easy opening system; Aluminium bar-friendly user roof system; High-quality awning weight 900 g/m; Side has 2x3 sliding stanchions and rear aluminium doors with 2x5 hinges and 2x2 integrated locking and bars |
